DETAILED INFORMATION
Developed specifically for chemical, oil & gas, deep water umbilical and deep water umbilical applications, hyper duplex grades meet the increasing demands of the chemical industry. Due to its corrosion resistance, such as pitting and crevice corrosion), and its high mechanical strength and tensile strength. Among the other properties of UNS S32707 2707 Hyper Duplex, there is its resistance to stress cracking caused by chlorine and sulphur, erosion corrosion, resistance to corrosion in acidic and alkaline environments, and its ability to weld well. They are therefore used as equipment in many industries, such as control lines, raw seawater injection lines, and chemical injection lines.
In order to reduce the gauging of the final product (lighter installations are the result), the Hyper-Duplex Stainless Steel's increased tensile strength could be used, thus proving to be an economically viable option without losing any of its corrosion resistance and strength. The Hyper-Duplex Stainless Steel Grade 2707 provides greater corrosion resistance, yield strength, and fatigue performance than other super duplex stainless steels. In the oil and gas industry, they are therefore used.
A Duplex stainless steel consists of two phases: ferrite and austenite in approximately equal amounts. As a result, they are both stronger, easier to weld, more tough and resistant to corrosion than austenitic stainless steels. Due to their lower nickel content, they are also more economically competitive than austenitic stainless steels.
Although duplex stainless steel was developed in Sweden in 1930, commercial production did not begin until the 1970s, due to its very complicated manufacturing process. Modern steelmaking techniques have made it easier to produce, resulting in a re-emergence of the metal. Although these stainless steels have significant advantages, they are still a relatively underutilized group, with about 1 - 3% of stainless steels being used globally due to their limitations.
CITIES WE DELIVER
Adoni, Amaravati, Anantapur, Chandragiri, Chittoor, Dowlaiswaram ,Eluru, Guntur, Kadapa, Kakinada, Kurnool, Machilipatnam, Nagarjunakoṇḍa, Rajahmundry, Srikakulam, Tirupati, Vijayawada, Visakhapatnam, Vizianagaram, Yemmiganur, Itanagar, Dhuburi, Dibrugarh, Dispur, Guwahati, Jorhat, Nagaon, Sivasagar, Silchar, Tezpur, Tinsukia, Ara, Barauni, Begusarai, Bettiah, Bhagalpur, Bihar, Sharif, Bodh Gaya, Buxar, Chapra, Darbhanga, Dehri, Dinapur Nizamat, Gaya, Hajipur, Jamalpur, Katihar, Madhubani, Motihari, Munger, Muzaffarpur, Patna, Purnia, Pusa, Saharsa, Samastipur, Sasaram, Sitamarhi, Siwan, Chandigarh, Ambikapur, Bhilai, Bilaspur, Dhamtari, Durg, Jagdalpur, Raipur, Rajnandgaon, Daman, Diu, Silvassa, Delhi, New Delhi, Madgaon, Panaji, Ahmadabad, Amreli, Bharuch, Bhavnagar, Bhuj, Dwarka, Gandhinagar, Godhra, Jamnagar, Junagadh, Kandla, Khambhat, Kheda, Mahesana, Morbi, Nadiad, Navsari, Okha, Palanpur, Patan, Porbandar, Rajkot, Surat, Surendranagar, Valsad, Veraval, Ambala, Bhiwani, Chandigarh, Faridabad, Firozpur Jhirka, Gurugram, Hansi, Hisar, Jind, Kaithal, Karnal, Kurukshetra, Panipat, Pehowa, Rewari, Rohtak, Sirsa, Sonipat, Bilaspur, Chamba, Dalhousie, Dharmshala, Hamirpur, Kangra, Kullu, Mandi, Nahan, Shimla, Una, Anantnag, Baramula, Doda, Gulmarg, Jammu, Kathua, Punch, Rajouri, Srinagar, Udhampur, Bokaro, Chaibasa, Deoghar, Dhanbad, Dumka, Giridih, Hazaribag, Jamshedpur, Jharia, Rajmahal, Ranchi, Saraikela, Badami, Ballari, Bengaluru, Belagavi, Bhadravati, Bidar, Chikkamagaluru, Chitradurga, Davangere, Halebid, Hassan, Hubballi-Dharwad, Kalaburagi, Kolar, Madikeri, Mandya, Mangaluru, Mysuru, Raichur, Shivamogga, Shravanabelagola, Shrirangapattana, Tumakuru, Vijayapura, Alappuzha, Vatakara, Idukki, Kannur, Kochi, Kollam, Kottayam, Kozhikode, Mattancheri, Palakkad, Thalassery, Thiruvananthapuram, Thrissur, Kargil, Leh, Balaghat, Barwani, Betul, Bharhut, Bhind, Bhojpur, Bhopal, Burhanpur, Chhatarpur, Chhindwara, Damoh, Datia, Dewas, Dhar, Dr. Ambedkar Nagar (Mhow), Guna, Gwalior, Hoshangabad, Indore, Itarsi, Jabalpur, Jhabua, Khajuraho, Khandwa, Khargone, Maheshwar, Mandla, Mandsaur, Morena, Murwara, Narsimhapur, Narsinghgarh, Narwar, Neemuch, Nowgong, Orchha, Panna, Raisen, Rajgarh, Ratlam, Rewa, Sagar, Sarangpur, Satna, Sehore, Seoni, Shahdol, Shajapur, Sheopur, Shivpuri, Ujjain, Vidisha, Ahmadnagar, Akola, Amravati, Aurangabad, Bhandara, Bhusawal, Bid, Buldhana, Chandrapur, Daulatabad, Dhule, Jalgaon, Kalyan, Karli, Kolhapur, Mahabaleshwar, Malegaon, Matheran, Mumbai, Nagpur, Nanded, Nashik, Osmanabad, Pandharpur, Parbhani, Pune, Ratnagiri, Sangli, Satara, Sevagram, Solapur, Thane, Ulhasnagar,n Vasai-Virar, Wardha, Yavatmal, Imphal, Cherrapunji, Shillong, Aizawl, Lunglei, Kohima, Mon, Phek, Wokha, Zunheboto, Balangir, Baleshwar, Baripada, Bhubaneshwar, Brahmapur, Cuttack, Dhenkanal, Kendujhar, Konark, Koraput, Paradip, Phulabani, Puri, Sambalpur, Udayagiri, Karaikal, Mahe, Puducherry, Yanam, Amritsar, Batala, Chandigarh, Faridkot, Firozpur, Gurdaspur, Hoshiarpur, Jalandhar, Kapurthala, Ludhiana, Nabha, Patiala, Rupnagar, Sangrur, Abu, Ajmer, Alwar, Amer, Barmer, Beawar, Bharatpur, Bhilwara, Bikaner, Bundi, Chittaurgarh, Churu, Dhaulpur, Dungarpur, Ganganagar, Hanumangarh, Jaipur, Jaisalmer, Jalor, Jhalawar, Jhunjhunu, Jodhpur, Kishangarh, Kota, Merta, Nagaur, Nathdwara, Pali, Phalodi, Pushkar, Sawai Madhopur, Shahpura, Sikar, Sirohi, Tonk, Udaipur, Gangtok, Gyalshing, Lachung, Mangan, Arcot, Chengalpattu, Chennai, Chidambaram, Coimbatore, Cuddalore, Dharmapuri, Dindigul, Erode, Kanchipuram, Kanniyakumari, Kodaikanal, Kumbakonam, Madurai, Mamallapuram, Nagappattinam, Nagercoil, Palayamkottai, Pudukkottai, Rajapalayam, Ramanathapuram, Salem, Thanjavur, Tiruchchirappalli, Tirunelveli, Tiruppur, Thoothukudi, Udhagamandalam, Vellore, Hyderabad, Karimnagar, Khammam, Mahbubnagar, Nizamabad, Sangareddi, Warangal, Agartala, Agra, Aligarh, Amroha, Ayodhya, Azamgarh, Bahraich, Ballia, Banda, Bara Banki, Bareilly, Basti, Bijnor, Bithur, Budaun, Bulandshahr, Deoria, Etah, Etawah, Faizabad, Farrukhabad-cum-Fatehgarh, Fatehpur, Fatehpur Sikri, Ghaziabad, Ghazipur, Gonda, Gorakhpur, Hamirpur, Hardoi, Hathras, Jalaun, Jaunpur, Jhansi, Kannauj, Kanpur, Lakhimpur, Lalitpur, Lucknow, Mainpuri, Mathura, Meerut, Mirzapur-Vindhyachal, Moradabad, Muzaffarnagar, Partapgarh, Pilibhit, Prayagraj, Rae Bareli, Rampur, Saharanpur, Sambhal, Shahjahanpur, Sitapur, Sultanpur, Tehri, Varanasi, Almora, Dehra Dun, Haridwar, Mussoorie, Nainital, Pithoragarh, Alipore, Alipur Duar, Asansol, Baharampur, Bally, Balurghat, Bankura, Baranagar, Barasat, Barrackpore, Basirhat, Bhatpara, Bishnupur, Budge Budge, Burdwan, Chandernagore, Darjeeling, Diamond Harbour, Dum Dum, Durgapur, Halisahar, Haora, Hugli, Ingraj Bazar, Jalpaiguri, Kalimpong, Kamarhati, Kanchrapara, Kharagpur, Cooch Behar, Kolkata, Krishnanagar, Malda, Midnapore, Murshidabad, Nabadwip, Palashi, Panihati, Purulia, Raiganj, Santipur, Shantiniketan, Shrirampur, Siliguri, Siuri, Tamluk, Titagarh
2707 Hyper Duplex UNS S32707 Steel Specification:
Material: 2707 Hyper Duplex Steel, SS 2707, EN 1.4658
Special Properties: UNS S32707 Hyper Duplex Alloy
2707 Hyper Duplex Pipe & Tube : ASTM A790, A928, A789, Welded Pipe, Seamless Pipe
2707 Hyper Duplex Plate & Sheet : ASTM A240 Coils, Plate, Clad Plate, Plain Sheet, Foils, Flat, Shim Sheet, Sheet, Strip
2707 Hyper Duplex Round Bar & Rods : ASTM A276 Flat Bar, Hex Bar, Round Rods, Round Bar
Alloy | 1.4658 AISI product Material No. | UNS | EN Designation |
2707 | EN 1.4658 | S32707 | DIN X2CrNiN23-4 |
Hyper Duplex 2707 Product Chemical Composition
Mo | P | Mn | |
UNS: S32707 (2707 HD) | 4.8 | ≤0.035 | ≤1.5 |
UNS: S32707 (2707 HD) | 3.5 | ≤0.035 | ≤1.5 |
S | Si | C | Cr | Ni |
≤0.010 | ≤0.5 | ≤0.030 | 27 | 6.5 |
≤0.010 | ≤0.8 | ≤0.030 | 32 | 7 |
2707 Hyper Duplex Mechanical properties
Density: 7.8 g/cm3, 0.28lb/in3
Hyper Duplex Material Equivalent Grades
Grade | UNS | EN Number | PRE |
SAF 2707 HD | S32707 | 1.4658 | 48 |
SAF 3207 HD | S33207 | 50 |
ASTM Specifications
Pipe & Tube | Sheet/Plate | Bar |
A790, A928, A789 | A240 | A276 |
2707 Hyper Duplex (UNS S32707)
The 2707 Hyper Duplex stainless steel (UNS S32707) is a high-alloy duplex steel with a PRE value of at least 48*.
- A high level of corrosion resistance, particularly in pits and crevices
- A hyper duplex steel that has a high resistance to stress corrosion cracking (SCC) in chloride-containing environments is 2707 Hyper Duplex.
- Mechanical strength that is extremely high
- Aspects of physical properties that contribute to design success
- Weldability is excellent
- Acidic environments are resistant to general corrosion
- Exceptional resistance to erosion and corrosion
- Fatigue properties that are excellent against corrosion
Hyper Duplex Properties
Figs. 1A, 1B, 1C, and 1D illustrate solution annealed seamless tubes with walls up to 4 mm in thickness.
At 20°C (68°F)
Proof strength, MPa | Tensile strength, MPa | Elongation, % | Hardness, HRC | ||
Rp0.2a) | Rp1.0a) | Rm | Ab) | A2" | |
≥700 | ≥800 | 920-1100 | ≥25 | ≥25 | ≤34 |
Proof strength, ksi | Tensile strength, ksi | Elongation, % | Hardness, HRC | ||
Rp0.2a) | Rp1.0a) | Rm | Ab) | A2" | HRC |
≥101 | ≥116 | 133-160 | ≥25 | ≥25 | ≤34 |
1MPa = 1N/mm2
- a) Rp0.2 and Rp1.0 correspond to 0.2% offset and 1.0% offset yield strength, respectively.
- b) Based on L0 = 5.65 √S0 where L0 is the original gauge length and S0 the original cross-section area.
Hyper Duplex 3207 (UNS S33207)
Stainless steel hyper-duplex 3207 (UNS S33207) is a high-alloy duplex steel that has a PRE value of at least 50*.
- Excellent resistance to pitting and crevice corrosion
- The Hyper Duplex 3207 is highly resistant to stress corrosion cracking (SCC) in hydrogen sulphide (H2S) and chloride environments
- Excellent corrosion fatigue properties
- Exceptionally high mechanical strength
- Exceptionally high fatigue strength
- Acidic and caustic environments are highly resistant to corrosion
- Excellent resistance to erosion corrosion
- Physical properties that offer design advantages
- Good weldability
Specific heat capacity
Temperature, °C | J/(Kg °C) | Temperature, °F | Btu/(lb °F) |
20 | 470 | 68 | 0.11 |
100 | 495 | 200 | 0.12 |
200 | 530 | 400 | 0.13 |
300 | 560 | 600 | 0.13 |
400 | 590 | 800 | 0.14 |
Thermal conductivity
Temperature, °C | 20 | 100 | 200 | 300 | 400 |
SAF 2707 HD | 12 | 14 | 16 | 18 | 19 |
AISI 316L | 14 | 15 | 17 | 18 | 20 |
1) W/(m °C)
Temperature, °F | 68 | 200 | 400 | 600 | 800 |
SAF 2707 HD | 7 | 8 | 9 | 10 | 11 |
AISI 316L | 8 | 9 | 10 | 10 | 12 |
Thermal expansion
SAF 2707 HD has a coefficient of thermal expansion at the same level as carbon steel. The values given are average values in the temperature ranges.
Temperature, °C | 30-100 | 30-200 | 30-300 | 30-400 |
SAF 2707 HD | 12.5 | 13 | 13.5 | 14 |
AISI 316L | 16.5 | 17 | 17.5 | 18 |
1) x10-6/°C
Temperature, °F | 86-200 | 86-400 | 86-600 | 86-800 |
SAF 2707 HD | 7 | 7.5 | 7.5 | 7.5 |
AISI 316L | 9.5 | 9.5 | 10 | 10 |
1) x10-6/°F
Temperature, °C | µΩm | Temperature, °F | µΩin. |
22 | 0.75 | 72 | 29.5 |
Temperature, °C | MPa | Temperature, °F | ksi |
20 | 197 | 68 | 28.5 |
100 | 189 | 200 | 27.5 |
200 | 178 | 400 | 25.7 |
300 | 168 | 600 | 24.2 |
1) ( x103 )
Hyper Duplex Stainless Steel for sale
- Hot sale Hyper Duplex 2707 2B No.1 No.4 duplex stainless steel sheet plate
FOB Price US $1.85 / Kilogram - 18mm thick Hyper duplex stainless steel plate price
FOB Price US $1,000.00-$2,500.00 / Ton - Hyper duplex steel Plate
FOB Price US $2,000.00-$2,200.00 / Ton - Hyper duplex Sandvik 3207 plate / sheet
FOB Price US $1,000.00-$3,000.00 / Ton - Hyper duplex ss clad plate for shipbuilding industry
FOB Price US $1.80-$2.70 / Kilogram - Large stock UNS S32707 Hyper duplex stainless steel sheet plate
FOB Price US $1,500.00 / Ton - S32707 Hyper Duplex steel plate price list per kg
FOB Price US $1,200.00-$1,700.00 / Ton
Hyper Duplex 2707 Material
Hyper Duplex 2707 Supplier | 2707 Hyper Duplex Exporters | S32707 Duplex Alloy Material |
Hyper Duplex 2707 Material | S32707 Hyper Duplex Product | 2707 Hyper Duplex Alloy |
UNS S32707 Hyper Duplex Sheet | 2707 Hyper Duplex Alloy Plate | 2707 Hyper Duplex Pipe |
Steel S32707 Hyper Duplex Round Bar | Hyper Duplex 3201 Polished Bar | 2707 Hyper Duplex Round Rods |
2707 Hyper Duplex Material | Hyper Duplex S32707 Product | 2707 Stainless Steel Material |
Available Grades
Grades | Forms |
1.4462 (F51 & F60) | Round bars, Billets & Ingots |
1.4410 (F53) | Round bars, Billets & Ingots |
1.4501 (F55) | Ingots |
1.4821 | Round bars, Billets & Ingots |
1.4460 (329) | Round bars, Billets & Ingots |
1.4362 (2304) | Round bars, Billets & Ingots |
Classification of Duplex Stainless steel
Below are a few of the popular duplex stainless steel grades.
Type | Grades | ||
Common name | UNS Number | BS EN number | |
Lean Duplex | 2304 | S32304 | 1.4362 |
Duplex | 2205 (F51, F60) | S31803, S32205 | 1.4462 |
Super Duplex | 2507 (F53) | S32750 | 1.4410 |
Hyper Duplex | Sandvik SAF2707 | S32707 |
Properties of Duplex Stainless Steel
Corrosion Resistance
As a result of chromium and molybdenum in combination, duplex stainless steel grades offer corrosion resistance properties comparable to those of austenitic steel grades. The higher the Chromium content, the more resistant it is to pitting and crevice corrosion. Pitting Resistance Equivalent Numbers (PRENs) are used to rank the grades according to their resistance to pitting corrosion. A higher PREN number indicates a stronger resistance to pitting corrosion.
Stress Corrosion Cracking (SCC) Resistance
SCC is more common in austenitic grades, while ferritic grades are less likely to happen. Duplex stainless steels are more resistant to SCC than austenitic stainless steels but are inferior to ferritic stainless steels. SCC begins in austenitic regions in duplex stainless steels, but is arrested by a ferritic crystal structure present at the boundary, which prevents crack propagation and increases uptime.
Mechanical Strength
The mechanical strength of duplex stainless steel is higher than that of austenitic steels and ferritic steels. Due to its higher mechanical strength, duplex stainless steel machining is slower and more challenging than austenite. It allows thinner sections to be used, allowing for weight reduction.
Welding
Compared to austenite, welding is much more difficult. Close consideration must be given to the heat input and cooling rate in order to prevent the formation of intermetallic phases.
Advantage of Duplex stainless steel
When lighter fabrications are desired, higher strength enables thinner gauges to be used
- The price of stainless steel is mostly driven by the price of one particular commodity, that of nickel. So the price of stainless steel is relatively immune to fluctuating commodity prices, as Duplex stainless steel has relatively low nickel content.
The price of stainless steel is mostly driven by the price of one particular commodity, that of nickel. So the price of stainless steel is relatively immune to fluctuating commodity prices, as Duplex stainless steel has relatively low nickel content.
Applications and Uses of Duplex Stainless Steels
- Various types of pressure vessels, tanks, pipework, and heat exchangers are used in chemical processing, transport, and storage
- The piping, tubing, and heat exchangers required for oil and gas exploration and processing
- Chloride-rich environments in the marine environment
- The pulp and paper industry uses a variety of equipment for digestion, bleaching, and handling stocks
- Tanks for ships and trucks that carry cargo
- Machines used in food processing
- Plants that convert biomass into fuels
